Item # |
Description |
Part Number |
| 1 |
FLOW TEST KIT - BDP - G2 |
609009 |
| 1 |
FRAME - LOWER - AC FRNT PRT G2 |
644234 |
| 2 |
FRAME - UPPER G2 |
643871 |
| 3 |
STEP BUSHING |
257037 |
| 4 |
HEX BOLT |
243220 |
| 5 |
WASHER |
774020 |
| 6 |
NUT INSERT NYLON |
253450 |
| 7 |
SPRING - COMPRESSION |
283516 |
| 8 |
BOLT WHIZ FLANGE |
253203 |
| 9 |
CAP - SEAT SPRING |
422127 |
| 10 |
THROTTLE ASSY - 718K/720K/725K |
603821 |
| |
CONTROL CABLE ASSY |
323655 |
| |
STOP - THROTTLE LEVER |
722009 |
| 11 |
GRIP HANDLE |
422150 |
| 12 |
SPACER |
902280 |
| |
HEX BOLT |
243330 |
| |
WASHER |
257040 |
| 13 |
TOOL BOX |
422040 |
| 14 |
FENDER W/DECAL 700/900S RT |
693210 |
| 15 |
FENDER W/DECAL 700/900S LT |
693211 |
| 16 |
TRIM - FENDER EDGE 700/900 |
822635 |
| 17 |
COVER PANEL - FENDER RT |
722062 |
| 18 |
WHEEL & TIRE - BAR TREAD 10RT |
483942 |
| |
WHEEL - 10 - 5 BOLT |
483420 |
| |
TIRE - BAR TREAD 22 X 11 X 10 |
482483 |
| |
WHEEL & TIRE TURF 10 |
483924 |
| |
TIRE - TURF - 10 |
482474 |
| 19 |
WHEEL & TIRE - BAR TREAD 10 LT |
483943 |
| |
WHEEL - 10 - 5 BOLT |
483420 |
| |
TIRE - BAR TREAD 22 X 11 X 10 |
482483 |
| |
WHEEL & TIRE TURF 10 |
483924 |
| |
TIRE - TURF - 10 |
482474 |
| 20 |
ENGINE 25HP KOHLER |
100168 |
| 21 |
FILTER - OIL KOHLER |
100802 |
| 22 |
FILTER AIR HD OUTER |
100936 |
| |
FILTER AIR INNER HD |
100937 |
| 23 |
SHIELD COUPLER |
644291 |
| 24 |
MUFFLER KOHLER |
101217 |
| |
GASKET - EXHAUST - KOHLER |
101041 |
| 25 |
FILTER - FUEL KOHLER |
101001 |
| 26 |
BRACKET - SHIELD MOUNT W/A |
643117 |
| 27 |
BRACKET - LOWER MUFFLER |
729270 |
| 28 |
SHIELD - INNER PANEL |
722309 |
| 29 |
SHIELD MUFFLER |
722391 |
| 30 |
CONSOLE W/DECAL 96 AC |
693100 |
| 31 |
PANEL - FILL- 96 CONSOLE |
721152 |
| 32 |
MECHANICAL CHOKE |
142233 |
| 33 |
TANK - FUEL W/DRAW TUBE |
603813 |
| 34 |
TUBE FUEL DRAW |
643144 |
| 35 |
CLAMP HOSE SPRING |
141125 |
| 36 |
HOSE FUEL |
101819 |
| 37 |
SHIELD - HEAT FUEL TANK RIGHT |
280260 |
| 38 |
COUNTERWEIGHT - 34# |
821710 |
| 39 |
WEIGH COVER 34 LB |
721123 |
| 40 |
CARRIAGE BOLT |
323933 |
| 41 |
Weight Cover |
729514 |
| 42 |
Carraige Bolt |
247325 |
| 43 |
CARRIAGE BOLT SPECIAL |
643092 |
| 44 |
BUSHING - DECK MOUNT |
643093 |
| 45 |
Carriage Bolt Special |
247280 |
| 46 |
Bushing - Deck Mount |
282575 |
| 47 |
Bushing - Deck Mount - Floating |
282576 |
| 48 |
Nut - Insert - Nylon |
253460 |
| 49 |
Foot Platform Assy - ADJ 700/900 |
604346 |
| 50 |
TREAD - FOOT REST |
420905 |
| 51 |
NYLON BEARING |
422615 |
| 52 |
PIVOT ROD - FOOT PLATFORM 700 |
780673 |
| 53 |
NUT INSERT NYLON |
253470 |
| 54 |
RUBBER BUMPER |
424052 |
| 55 |
EXTENSION - 700 FOOT PLATFORM |
603301 |
| 56 |
TREAD - FOOT REST EXT |
420904 |
| 57 |
CARRIAGE BOLT |
247130 |
| 58 |
BOLT WHIZ HEX FLANGE |
253192 |
| 59 |
NUT WHIZ |
253035 |
| 60 |
SPRING COMPRESSION |
283312 |
| 61 |
ISOLATOR BLOCK - FOOTREST |
424100 |
| 62 |
HEX BOLT |
243026 |
| 63 |
TRASH SHIELD G2 |
721383 |
| 64 |
BATTERY BOX G2 AC W/A |
644099 |
| 65 |
COVER BATTERY AC W/A |
644162 |
| 66 |
PAD - BATTERY TRAY |
427273 |
| 67 |
CLAMP - BATTERY 700 G2 |
729001 |
| 68 |
WASHER |
257020 |
| 69 |
BOLT WHIZ HEX FLANGE |
253174 |
| 70 |
NUT WHIZ |
253025 |
| 71 |
BOLT WHIZ HEX |
253173 |
| 72 |
BOLT WHIZ TRUSS |
253176 |
| 73 |
NUT-SPEED |
254431 |
| 74 |
RUBBER BUMPER |
424015 |
| 75 |
GUSSET - ROPS RT |
726131 |
| 76 |
GUSSET - ROPS LT |
726132 |
| 77 |
PLUG SQ PLASTIC |
422065 |
| 78 |
REINFORCEMENT - BRAKE PIN |
729230 |
| 79 |
DECAL SET - 725K2 W/SIDE CONSOLE |
604296 |
