Item # |
Description |
Part Number |
1 |
Traction Kit W/A Pin |
644635 |
2 |
600 w/SL Deck Lift Strap |
732410 |
3 |
Rocker w/o Extension - right |
603701 |
- |
Oilite Bearing |
121766 |
4 |
Rocker w/o Extension - left |
603702 |
- |
Oilite Bearing |
121766 |
5 |
Hex Flange Whiz Bolt .312-18 x .75 |
253192 |
6 |
Whiz Nut |
253035 |
7 |
Pin - Cylinder Mount w/Groove |
887119 |
8 |
Hydraulic Cylinder |
290021 |
- |
Hydraulic Lift Cylinder HD Seal Kit |
290096 |
9 |
Adapter O Ring |
360052 |
10 |
Traction Kit Spring Assembly |
605760 |
11 |
Hex Bolt |
243395 |
12 |
Nut .375-16 |
254450 |
13 |
External Retainer |
263500 |
14 |
Clevis Pin |
261339 |
15 |
Cotter Pin |
260648 |
16 |
Lift 3 Links Chain |
820317 |
17 |
Washer |
257040 |
18 |
Hair Pin |
260523 |
19 |
Pump Mount Plate |
725326 |
20 |
Hydraulic Pump w/Solenoid Valve - CCW |
290074 |
21 |
Hydraulic Valve Solenoid |
144950 |
22 |
90 degree Adapter O-Ring |
360055 |
23 |
Adapter O-Ring |
360045 |
24 |
Adapter Swivel Tee |
360005 |
25 |
Hose Assembly |
424310 |
26 |
Steel O Ring Boss Fitting |
363832 |
27 |
Fitting |
363857 |
28 |
Spring Hose Clamp |
280266 |
29 |
Adapter O-Ring |
360040 |
30 |
Reducer Tee |
366115 |
31 |
Adapter Fitting |
360012 |
32 |
Brass Hose Insert |
360260 |
33 |
Adapter O-ring |
360050 |
34 |
Hose Assembly |
424302 |
35 |
.5 Hydraulic Hose |
821806 |
36 |
Whiz Flange Bolt |
253203 |
37 |
Whiz Nut |
253043 |
38 |
Square Key |
281540 |
39 |
Coupler Hub |
388576 |
40 |
Coupling Stabilizer |
424150 |
41 |
Nylon Coupler Sleeve |
388560 |
42 |
Hex Bolt |
243331 |
43 |
Lock Washer |
257412 |
44 |
Washer |
774020 |
45 |
Lower Flex Coupler |
831039 |
46 |
Square Key |
281580 |
47 |
Washer |
770045 |
48 |
Washer |
257106 |
49 |
Carriage Bolt .375 x 1.375 |
247254 |
50 |
Flow Restrictor |
780507 |
51 |
Clevis Pin |
261336 |
52 |
Lock Nut |
253890 |
53 |
Beaded O-ring Adapter 3 |
360075 |
54 |
Hydraulic Hose |
821781 |
55 |
Wide STD Strg Lever Assembly w/SW |
604779 |
56 |
Hyd Lift Switch / MT Assembly |
604799 |
57 |
Handle Grip |
422179 |
58 |
.75 ID Vinyl Cap |
422095 |
59 |
Hydraulic Pump Plate Shim |
900105 |
