1

Sheave

415826

2

Spacer

282630

3

Hex Bolt

243331

4

Cupped Washer

257041

5

Ball Bearing without Fluid Seal

120081

6

Grease Spindle Housing

320526

7

Zerk Grease Fitting

280734

8

Tube Bearing Spacer

903640

9

Blade Std Spindle Shaft

603775

10

Fiber Washer

421200

11

Washer

257061

12

Lock Washer

257432

13

Hex Bolt

243581

14

Blade Spindle Assembly (includes items 3-13)

623785

15

15" Hi-Lift Notch Blade

320234

-

15" Medium-Lift Blade

320231

16

right 9044 Belt Shield

722308

17

Belt Shield Assembly

603769

18

Rubber Draw Latch

281301

19

Belt

382990

20

9044 Deck Weldment

643258

21

Extension Spring with Swivel

283820

22

Idler Adjustment "J" Bolt

730391

23

Idler

393225

24

Idler Spacer

902325

25

Hex Bolt

243600

26

Nut

254470

27

Idler Arm with Bearing & Pedestal

824502

28

Pedestal Bearing

121650

29

Hex Bolt

243365

30

Vinyl Cap

422098

31

Hex Bolt

243565

32

Washer

257062

33

Whiz Nut

253043

34

Washer

257040

35

90 Series Discharge Shield

643747

36

Hitch Pin

260400

37

Clevis Shaft

643235

38

Upper Right Lift Channel

643500

39

Upper Left Lift Channel

643501

40

Deck Stabilizer with Bumper

822312

41

Rubber Bumper

424052

42

Right Fork Mount with Bearing

603351

43

Left Fork Mount with Bearing

603352

44

Zerk Grease Fitting

280776

45

Flanged Sintered Bushing

833260

46

90 Series Deck Fork

604350

47

9 x 3.5 x 4 Semi-Pneumatic Wheel Assembly

603971

48

Deck Wheel Bearing Spacer

902473

49

Ball Bearing

120050

50

Axle Spacer

902415

51

Carriage Bolt

247715

52

Lock Nut

253970

53

Washer

774014

54

Lock Washer

257412

55

44" Deck Linkage Arm

603563

56

Lift Lever Linkage

603562

57

Clevis Yoke

265554

58

Nut

254475

59

Hex Bolt

243609

60

Hex Bolt

243614

61

Lock Nut

253930

62

Cotter Pin

260650

63

Clevis Pin

261426

64

Clevis Pin

261346

65

Hex Bolt

243580

66

Speed Nut

254431

67

Counter-Clockwise Right Angle Gearbox

390024

68

Woodruff Key

281833

69

Woodruff Key

281828

70

Sheave

415876

71

44&34; Mower Lift Arm

643525

72

Attaching Pin

643625

73

Safety Pin

261848

74

Deck Lift Lever

643529

75

Handle Grip

422155

76

Handle Grip

422158

77

UN Half Shaft

398525

78

Yoke

401010

79

Cross & Bearing

121010

80

Yoke & Shaft

402605

81

Square Key

281580

82

Hex Flange Whiz Bolt

253192

83

Hex Whiz Bolt

253173

84

Mower Safety Decal Set

603280
