Item # |
Description |
Part Number |
1 |
Blade Spindle Assembly (right) |
623784 |
- |
Blade Spindle Assembly (left & center) |
623783 |
2 |
Bolt |
243331 |
3 |
Cupped Washer |
257041 |
4 |
Ball Bearing |
110082 |
5 |
Spindle Housing |
320526 |
6 |
Grease Fitting |
280734 |
7 |
Bearing Spacer Tube |
903640 |
8 |
Blade Spindle (right) |
604770 |
- |
Blade Spindle (left & center) |
604768 |
9 |
Fiber Washer |
421200 |
10 |
Flat Washer |
257061 |
11 |
Lock Washer |
257432 |
12 |
Bolt |
243581 |
13 |
Spacer |
282607 |
14 |
Square Key (right spindle) |
281580 |
- |
Square Key (left & center spindle) |
281583 |
15 |
Whiz Bolt |
253192 |
