Item # |
Description |
Part Number |
1 |
700T AC Lower Frame |
644873 |
2 |
700T Upper Frame |
644874 |
3 |
Hex Flange Whiz Bolt |
253192 |
4 |
Whiz Nut |
253035 |
5 |
Tension Rod |
780900 |
6 |
Bolt Whiz |
253200 |
7 |
Flood Worklamp |
182253 |
8 |
Snap Mount Worklamp Bezel |
182251 |
9 |
Flange Bolt Whiz |
253203 |
10 |
Throttle Assembly |
603821 |
- |
Control Cable Assembly |
323655 |
- |
Throttle Lever Stop |
722009 |
11 |
Handle Grip |
422150 |
12 |
Spacer |
902280 |
13 |
Hex Bolt |
243335 |
14 |
Washer |
257040 |
15 |
Fender W/Safety Decal RT |
693210 |
- |
Decal - 729 Big Block Trim RT |
163480 |
16 |
Fender W/Safety Decal LT |
693211 |
- |
Decal - 729 Big Block Trim LT |
163481 |
17 |
right Fender Cover Panel |
722062 |
18 |
right Wheel & Bar Tread Tire, 22 x 11 x 10 |
483942 |
- |
5 Bolt Wheel Only, 10 x 8.5 |
483420 |
- |
Bar Tread Tire Only, 22 x 11 x 10 |
482483 |
- |
Wheel & Turf Tire, 22 x 10 x 10 |
483946 |
- |
Turf Tire Only, 22 x 10 x 10 |
482473 |
19 |
left Wheel & Bar Tread Tire, 22 x 11 x 10 |
483943 |
- |
5 Bolt Wheel Only, 10 x 8.5 |
483420 |
- |
Bar Tread Tire Only, 22 x 11 x 10 |
482483 |
- |
Wheel & Turf Tire, 22 x 10 x 10 |
483946 |
- |
Turf Tire Only, 22 x 10 x 10 |
482473 |
20 |
29HP B & S Engine |
100194 |
21 |
Briggs Oil Filter |
100803 |
22 |
Air Cleaner |
100209 |
- |
Air Hood |
100203 |
- |
Air Filter - Outer HD |
100936 |
- |
Air Filter - Inner HD |
100937 |
23 |
In-Line Fuel Filter Briggs |
366560 |
24 |
Muffler |
101255 |
25 |
Muffler Shield Bracket |
766171 |
26 |
Muffler Shield |
722837 |
27 |
Muffler Shield Outer |
722841 |
28 |
Tool Box |
422040 |
29 |
Fender Edge Trim - 700/900 |
822635 |
30 |
Console w/Decal - 96 AC |
693100 |
31 |
Console Panel Fill - 96 |
721152 |
32 |
Mechanical Choke |
142233 |
33 |
8.0 Gas Tank Assembly |
604844 |
34 |
In-Tank Fuel Gauge |
141144 |
- |
Grommet |
424275 |
35 |
Fuel Cap |
100210 |
36 |
Fuel Tube Bushing |
101875 |
37 |
Fuel Tube |
363928 |
38 |
Fuel Hose |
821710 |
39 |
Hose Spring Clamp |
280260 |
40 |
34 LB Counterweight |
323933 |
41 |
34 LB Weight Cover |
729514 |
42 |
Carriage Bolt |
247325 |
43 |
700/900 right Quick Disconnect Deck Mount |
643092 |
44 |
700/900 left Quick Disconnect Deck Mount |
643093 |
45 |
Special Carriage Bolt |
247280 |
46 |
Deck Mount Bushing |
282575 |
47 |
Floating Deck Mount Bushing |
282576 |
48 |
Nylon Insert Nut |
253460 |
49 |
Adjustable Foot Platform Assembly - 700/900 |
604346 |
50 |
Foot Rest Tread |
420905 |
51 |
Nylon Bearing |
422615 |
52 |
Foot Platform Pivot Rod - 700 |
780673 |
53 |
Nylon Insert Nut |
253470 |
54 |
Rubber Bumper |
424052 |
55 |
Foot Platform Extension - 700 |
603301 |
56 |
Foot Rest Extension Tread |
420904 |
57 |
Carriage Bolt |
247130 |
58 |
8 Gallon Tank Shield |
723339 |
59 |
8 Gallon Tank Mount |
644826 |
60 |
Compression Spring |
283312 |
61 |
Footrest Isolator Block |
424100 |
62 |
Hex Bolt |
243026 |
63 |
Whiz Nut |
253043 |
64 |
Battery Box W/O Draw latch |
644163 |
65 |
Battery Box W/O Latch Lid |
644478 |
66 |
Battery Tray Pad |
427278 |
67 |
Battery Hold Down Bracket |
754135 |
68 |
Washer |
257020 |
- |
Nylon Nut Insert |
253440 |
69 |
Hex Bolt Whiz |
253175 |
70 |
Whiz Nut |
253025 |
71 |
Hex Bolt Whiz |
253173 |
72 |
Bolt Whiz Truss |
253176 |
73 |
Speed Nut |
254431 |
74 |
Rubber Bumper |
424015 |
75 |
Square Plastic Plug - 1 in. ID |
422065 |
76 |
Aluminum Washer |
773010 |
77 |
Adapter |
887123 |
78 |
Oil Drain Valve |
143610 |
79 |
Nylon Fitting |
363848 |
80 |
Lug Bolt |
248565 |
81 |
Washer |
257051 |
82 |
Lock Washer |
257422 |
83 |
Hex Bolt |
243445 |
84 |
Coupler Shield 700BT |
722985 |
85 |
8 Gallon Tank Heat Shield |
721181 |
86 |
729BT6 Decal Set |
605341 |
