Genuine OEM Grasshopper Lawn Mower Parts

Genuine OEM Grasshopper® Mower Parts Diagrams

932G2 • Steering Assembly

2002

Steering Assembly

Click On a Part Number Below for Details

NOTE: If the part number you select is not linked to the shopping cart,
call toll-free 866-698-4070 for availability.

Item #

Description

Part Number

1

Steering Lever Assembly - Wide STD

604778

2

Adjustable Steering Lever Mount

643926

3

Hex Flange Whiz Bolt

253195

4

Whiz Nut

253035

5

Handle Grip

422179

6

.75 ID Vinyl Cap

422095

7

Steering Pivot with Stop & Bearings - right

604771

8

Steering Pivot with Stop & Bearings - left

604772

9

Sleeve Bearing w/Flange

422559

10

Sleeve Bearing

422557

11

Set Screw

259305

12

Washer

257063

13

Sleeve Bearing w/Flange

422556

14

Compression Spring

283324

15

Nylon Insert Nut

253470

16

Hex Bolt

243197

17

Wide Std Steering Lever Assembly with Swivel

604779

18

Sealed Dome Switch

183940

19

Adjustable Lever Nut

254438

20

Flat Washer

257019

return to 932G2 index return to top of page
