Item # |
Description |
Part Number |
1 |
PIVOT TUBE - DISC BRAKE |
643280 |
2 |
RETAINER EXTERNAL |
263529 |
3 |
ROD - LINKAGE STEERING |
730289 |
4 |
ROD - DISC BRAKE LOWER LT |
730355 |
5 |
ROD - DISC BRAKE ADJUSTABLE |
730356 |
6 |
LEVER ASSEMBLY - BRAKE 700 |
603557 |
7 |
GRIP HANDLE |
422150 |
8 |
BRACKET - NEUTRAL RETURN SPRING |
729072 |
9 |
SPRING - EXTENSION |
283823 |
10 |
HEX BOLT |
243030 |
11 |
NUT WHIZ |
253025 |
12 |
MOUNT - NEUTRAL PIVOT |
643603 |
13 |
ARM - W/BRG NEUTRAL RETURN |
603084 |
14 |
NYLON BEARING |
422560 |
15 |
WASHER |
257063 |
16 |
RETAINER EXTERNAL |
263500 |
17 |
BOLT WHIZ HEX |
253173 |
18 |
PIVOT - CONTROL LINKAGE |
643627 |
19 |
NYLON BEARING |
422585 |
20 |
LINKAGE PIVOT W/BRG |
603567 |
21 |
WASHER |
257030 |
22 |
COTTER PIN |
260624 |
23 |
ARM - CONTROL 700 |
643057 |
24 |
KEY WOODRUFF |
281823 |
25 |
ROLLER ASSY - ECCENTRIC |
603726 |
26 |
NUT |
254450 |
27 |
WASHER - LOCK |
257412 |
28 |
NUT |
254441 |
29 |
WASHER - LOCK |
257402 |
30 |
WASHER - FLAT |
774012 |
31 |
WASHER - LOCK |
257392 |
32 |
HEX BOLT |
243025 |
33 |
BALL JOINT |
265615 |
34 |
ROD - BALL JOINT |
780160 |
35 |
ROD - BALL JOINT |
780165 |
36 |
LEVER - DUMP VALVE |
730088 |
37 |
RETAINER PUSH-ON |
262934 |
38 |
YOKE CLEVIS |
265537 |
39 |
CLEVIS PIN |
261284 |
40 |
BRAKE DISC RT |
481120 |
41 |
BRAKE DISC LT |
481121 |
42 |
MOUNT - DISC BRAKE RT |
725205 |
43 |
MOUNT - DISC BRAKE LT |
725206 |
44 |
LINKAGE PIVOT W/BRG |
603567 |
