Item # |
Description |
Part Number |
| 1 |
GAUGE - TEMPERATURE |
141152 |
| 2 |
LIGHT INDICATOR |
182310 |
| 3 |
BUZZER & MOUNT ASSY |
603190 |
| 4 |
SWITCH & COVER ASSY - PTO |
604796 |
| 5 |
SWITCH - KEY - SEALED-KUBOTA |
183827 |
| 6 |
SWITCH - TOGGLE LIGHT |
183950 |
| 7 |
PUMP - FUEL ELECTRIC |
101510 |
| 8 |
SWITCH - LEVER |
183860 |
| |
MOUNT - STEERING SWITCH RT |
720160 |
| 9 |
SWITCH - LEVER |
183860 |
| |
MOUNT - STEERING SWITCH LT |
720161 |
| 10 |
WORKLAMP ASSY |
182265 |
| 11 |
LAMP HOUSING |
182350 |
| 12 |
GASKET - LIGHT ASSY |
420550 |
| 13 |
LAMP LENS |
182400 |
| 14 |
LIGHT BULB - WORKLAMP |
182000 |
| 15 |
MACHINE SCREW |
250258 |
| 16 |
CLIP CONDUIT |
180635 |
| 17 |
SWITCH - SEAT |
183870 |
| 18 |
RELAY 12VDC |
184272 |
| 19 |
TERMINAL BOARD - W/WIRES-721/25 |
603868 |
| 20 |
FLASHER 12 VOLT |
182440 |
| 21 |
FUSE BLOCK |
181722 |
| 22 |
FUSE - AUTO ATC - 30 |
181470 |
| |
FUSE = AUTO ATC - 15 |
181465 |
| |
FUSE - AUTO ATC - 7.50 |
181460 |
| 23 |
HOUR METER |
141551 |
| 24 |
SWITCH - BRAKE INTERLOCK |
183894 |
| 25 |
VOLTAGE REGULATOR 12 V. |
185530 |
| 26 |
BATTERY - 12VOLT SIDEPOST - WET |
180130 |
| |
BOX - BATTERY |
643135 |
| |
COVER - BATTERY BOX |
643241 |
| |
CLAMP - BATTERY |
720604 |
| 27 |
CABLE - BATTERY 11 RED |
180310 |
| |
BOOT BATTERY TERMINAL |
425219 |
| 28 |
CABLE - BATTERY 16 BLACK |
180276 |
| 29 |
MOUNT - FUSE BLOCK |
722204 |
| 30 |
COVER - FUSE BLOCK |
722176 |
| 31 |
TERMINAL BOARD - W/WIRES - 721/25 |
603868 |
