1

Linkage Latch Rod

643722

2

Hopper Top W\ Top 15B

643910

3

Right Door Latch

644155

4

Left Door Latch

644156

5

Inlet Tube Mod 16

644372

6

Door Linkage Mod 16

644458

7

Upper Crossmember 15B

645011

8

Lower Channel Mount 15B

645203

9

Right Hinge Mount

645260

10

Left Hinge Mount

645261

11

Hopper Door Mod15B

645285

12

Right Door Hinge

645410

13

Left Door Hinge

645411

14

Door Mount 15B

645571

15

Window Clip

720145

16

Bridge Stop Panel

721357

17

Right Side Panel 15B

721460

18

Left Side Panel 15B

721461

19

Panel Bottom 15B

721746

20

Screen Clamp

723081

21

Hopper Lever Stop

732592

22

Hopper Handle

734075

23

Right Door Latch Bracket 15B

754351

24

Left Door Latch Bracket 15B

754352

25

Spring Strap 700/900

755129

26

Right Hopper Side Reinforcement 15B

766260

27

Left Hopper Side Reinforcement 15B

766261

28

Door Panel 15B

721344

29

Bolt

253180

30

Inlet Baffle Mod16

721187

31

Pivot Bearing

822305

32

62" Flex Hose

424410

33

Rubber Bumper

424053

34

Inspection Window

423510

35

Nylon Bearing

422615

36

Handle Grip

422175

37

Top Screen 15B

721458

38

Extension Spring

283821

39

Swell Action Latch

281305

40

6" Hose Clamp

280345

41

Clevis Yoke

265545

42

Clevis Yoke

265537

43

Clevis Pin

261346

44

Clevis Pin

261284

45

Cotter Pin

260648

46

Cotter Ring

260608

47

Cotter Ring

260606

48

Hitch Pin

260400

49

Nut

254452

50

Nut

254441

51

Flanged Whiz Bolt

253203

52

Truss Whiz Bolt

253177

53

Truss Whiz Bolt

253176

54

Hex Whiz Bolt

253173

55

Whiz Nut

253043

56

Whiz Nut

253035

57

Whiz Nut

253025

58

Carriage Bolt

247130

59

Hex Bolt

243016

60

Hopper Screen Clamp

723022

61

Rear Hopper Mount 12C/15B

644534

62

Bottom Adjust Panel 15B

721749
