Genuine OEM Grasshopper Lawn Mower Parts

Genuine OEM Grasshopper® Mower Parts Diagrams

Strap Lift • Electric Lift Assembly

2007 and Older

Snowthrower Assembly

Click On a Part Number Below for Details

NOTE: If the part number you select is not linked to the shopping cart,
call toll-free 866-698-4070 for availability.

Item #

Description

Part Number

1

Aerator Acme THD Lift Shaft

644515

2

Right Extended Lift Linkage Mount

644563

3

Extended Lift Linkage Mount

644564

4

Strap Lift Guard

722063

5

Belt Guide Disk

775084

6

Switch Cover

721121

7

Aerator Relay Mount

729294

8

Lift Strap 18.625 "

420110

9

Lift Drive Assembly

604515

10

Aerator Switch Bracket

724039

11

Switch Lever

183855

12

Aerator Conduit Channel

724043

13

Eye Bolt

240058

14

Whiz Nut

253043

15

Aerator Switch Block

822317

16

Lead Screw Guide

830340

17

Aerator Activator Strap

782783

18

Hex Machine Screw

250169

19

Machine Screw

250318

-

Lock Washer

257372

20

Nut

254400

21

Square Key

281583

22

Hex Bolt

243040

23

Hex Flanged Whiz Bolt

253192

24

Hex Whiz Bolt

253173

25

Whiz Nut

253025

26

Accessories Switch Box

644772

27

Switch Box Cover Panel

721140

28

Rubber Bumper

424029

29

Grommet

424216

30

Throttle Lever Stop

722009

31

Switch Box Mount Strap

754005

32

Latch Spring Spacer

902263

33

Compression Spring

283324

34

Washer

257030

35

Hex Bolt

243215

36

Aeravator Universal WP Wire Group

604903

37

Electric Lift Kit

503317
