Item # |
Description |
Part Number |
1 |
600T Drive Train Mount |
643945 |
2 |
Parker Tandem Hydro |
391467 |
3 |
Tandem Transmission Filter |
130505 |
4 |
H2 & T Hydro Fan |
130431 |
5 |
Fan Retainer Washer |
130432 |
6 |
Nylon Insert Nut |
253461 |
7 |
O-Ring Adapter |
360061 |
8 |
O-Ring Adapter |
360059 |
9 |
T2 Expansion Tank Adapter |
130510 |
- |
O-Ring |
126550 |
10 |
Hose Assembly |
424338 |
11 |
Hose Assembly |
424352 |
12 |
Wheel Motor Front Port |
391475 |
- |
616T Hub & Rotor Assembly |
604438 |
13 |
90 Degree Adapter Fitting |
360078 |
14 |
Return Plastic Spacer |
422039 |
15 |
Tandem Pump Mount Spacer |
775123 |
16 |
Return Mount |
729542 |
17 |
Hex Bolt |
243045 |
18 |
Lock Washer |
257392 |
19 |
Hex Bolt |
243350 |
20 |
Lock Washer |
257412 |
21 |
Return Arm |
729639 |
22 |
Neutral Return Arm |
729398 |
23 |
Neutral Return Pivot Bearing |
822304 |
24 |
Fender Washer |
257044 |
25 |
Hex Bolt |
243335 |
26 |
Lock Nut |
253890 |
27 |
Extension Spring |
283823 |
28 |
Hex Bolt |
243035 |
29 |
Whiz Nut |
253025 |
30 |
Tandem Neutral Return Arm |
644862 |
31 |
600T Eccentric Roller Assembly |
603729 |
32 |
External Star Washer |
257410 |
33 |
Nut |
254450 |
34 |
Hex Bolt |
270832 |
35 |
Neutral Return Spacer |
783730 |
36 |
Hex Whiz Bolt |
253186 |
37 |
Flat Washer |
257019 |
38 |
Whiz Nut |
253038 |
39 |
Right Handed Thread Ball Joint |
265615 |
40 |
Left Handed Thread Ball Joint |
265616 |
41 |
Steering Link Rod |
780151 |
42 |
600T Steering Link Rod |
780153 |
43 |
Nut |
254441 |
44 |
Nut |
254444 |
45 |
Hex Bolt |
243215 |
46 |
Washer |
257030 |
47 |
Whiz Nut |
253035 |
48 |
Hex Bolt |
243565 |
49 |
Washer |
257060 |
50 |
Whiz Nut |
253066 |
51 |
Vibration Isolator |
424079 |
52 |
Whiz Nut |
253043 |
53 |
Tandem Pump Front Mount |
729529 |
54 |
Flanged Hex Whiz Bolt |
253192 |
55 |
H2 Fan Hub |
130430 |
56 |
DD Washer |
774175 |
57 |
Coupler Hub |
388577 |
58 |
Coupling Stabilizer |
424150 |
59 |
Hex Bolt |
243206 |
60 |
3" OD Washer |
774176 |
61 |
Nylon Coupler Sleeve |
388560 |
62 |
Square Key |
281580 |
63 |
Coupler Hub |
388578 |
64 |
Washer |
774020 |
65 |
Flanged Whiz Bolt |
253203 |
66 |
Oil Reservoir Bracket |
644094 |
67 |
Hydro Expansion Tank |
422033 |
68 |
3/8" Threaded Plastic Plug |
365516 |
69 |
Tie |
423154 |
70 |
Hydro Expansion Hose |
821709 |
71 |
Hose Spring Clamp |
280264 |
72 |
Clear Vent Hose |
821723 |
73 |
600T Fan Shroud |
722969 |
74 |
616T Coupler Shield |
722972 |
75 |
Whiz Nut |
274114 |
76 |
Spacer |
902555 |
