Genuine OEM Grasshopper® Mower Parts Diagrams
3344 Deck • Traction Kit Adapter
2014
Click On a Part Number Below for Details
NOTE: If the part number you select is not linked to the shopping cart,
call toll-free 866-698-4070 for availability.
Item # |
Description |
Part Number |
| 1 |
STRAP- LIFT 600 W/SL DECK |
732410 |
| 2 |
Cotter Pin |
260648 |
| 3 |
Clevis Pin |
261339 |
| 4 |
Clevis Pin |
261336 |
| 5 |
Lift Chain (3 Links) |
820317 |
| 6 |
616T Right Strap Lift |
725492 |
| 7 |
616T Left Strap Lift |
725493 |
