1

Hood Panel

643409

2

Trim - Hood Panel Hole

822633

3

Trim - Hood Panel Console

822650

4

Cowling Support--Right

643794

5

Cowling Support--Left

643793

6

Radiator

101605

7

Radiator Grille

643400

8

Radiator Mount

783208

9

Rear Hood Mount

643559

10

Flywheel Shield

643774

11

Flywheel Shield Cover

722167

12

Tractor Frame

643390

13

Kubota Diesel Engine 18 HP

100175

14

Air Filter

100940

15

Air Intake Hose

822650

16

Muffler & Gasket Assembly

603590

17

Washer

257067

18

Nut

830355

19

Fuel Prefilter

101005

20

Fuel Filter

101000

21

Fender - Right

643350

22

Fender - Left

643351

23

Trim - Fender Edge

822635

24

Steering Lever - Right

643534

25

Steering Lever - Left

643535

26

Handle Grip

422160

27

Console

643229

28

Front Console Panel

643624

29

Brake Band Lever

643518

30

Brake Linkage Rod

730292

31

Extension Spring - Fuel Shut Off

283764

32

Plug

422065

33

Handle Grip

422150

34

Foot Rest

643710

35

Bolt

259741

36

Rubber Bumper

424015

37

Mechanical Throttle

142295

38

Wheel & Tire - 20 x 10 x 8

483920

-

Wheel - 8 x 6

483410

39

Rear Axle Pivot Assembly

604597

40

Beam

824510

41

Oilite Bearing

833275

42

Washer

257061

43

Bolt

243560

44

Dust Cap

481432

45

Cotter Pin

260670

46

Nut

254502

47

Washer

257091

48

Bearing

122522

49

Bearing Cup

123522

50

Seal

125855

51

Fork & Nut Assembly - Rear

604364

52

Wheel & Tire w/Brg & Spacer - 13 x 5 x 6

483861

-

Tire - 13 x 5 x 6

482350

-

Wheel w/Brg & Spacer - 6 x 3.25

483301

53

Spacer

902475

54

Ball Bearing

120050

55

Spacer

902425

56

Bolt

247725

57

Mount - Lower Right Engine

726205

58

Mount - Lower Left Engine

726175

59

Mount - Upper Engine Right

643292

60

Mount - Upper Engine Left

643291

61

Vibration Isolator

424078

62

Voltage Regulator

185530

63

Mount - Fuel Solenoid

643591

64

Fuel Solenoid

180880

65

Cable Assembly - Fuel Solenoid

603209

66

Ball Joint

265610

67

Oil Filter - Kubota Diesel Engine

100800

68

Fuel Tank Assembly

603812

69

Fuel Tank Mounting Bracket

643144

70

Fuel Cap w/Level

141125

71

Fuel Draw Tube

101818

72

Hose Clamp

280270

73

Hose

821713

74

Barb Fitting

363825

75

Hose Clamp

280257

76

Hose - Return Line

821740

77

Steering Lever Pivot - Left

643640

-

Steering Lever Pivot - Right

643638

78

Compression Spring

283324

79

Washer

257063

-

Washer

257064

80

Nut

253470

81

Cotter Pin

260654

82

Nylon Bearing

422560

83

Nylon Bearing

422580

84

Nut

253970

85

Compression Spring

283381
