Genuine OEM Grasshopper® Mower Parts Diagrams
225 • Console
2021
Click On a Part Number Below for Details
NOTE: If the part number you select is not linked to the shopping cart,
call toll-free 866-698-4070 for availability.
Item # |
Description |
Part Number |
1 |
Briggs & Stratton / Kohler Ignition Switch with Key |
183806 |
- |
Indak Ignition Key with Cover |
101101 |
- |
.250 Terminal Pushon Type 1 |
184578 |
- |
.250 Terminal Pushon |
184580 |
- |
5-Way Connector Type 9 |
184925 |
- |
Nut |
254498 |
- |
Plastic Panel |
422078 |
2 |
Brake Light Indicator |
182326 |
3 |
Rocker Switch |
184179 |
4 |
Push/Pull Switch |
183925 |
- |
9-Way Connector |
184942 |
14 |
Fuel Level Guage & Hour Meter |
141122 |
22 |
Oil Indicator Light |
182327 |
25 |
Plastic Hole Plug |
422072 |
26 |
Console Decal |
161093 |
