Genuine OEM Grasshopper Lawn Mower Parts

Genuine OEM Grasshopper® Mower Parts Diagrams

321D • Steering Assembly

2017

Click On a Part Number Below for Details

NOTE: If the part number you select is not linked to the shopping cart,
call toll-free 866-698-4070 for availability.

Item #

Description

Part Number

1

Steering Lever Assembly - Wide STD

604778

2

Adjustable Steering Lever Mount

643926

3

Hex Flange Whiz Bolt

253195

4

Nylon Insert Nut

253450

5

Handle Grip

422179

6

Vinyl Cap .75 ID

422095

7

200V Right Steering Pivot with Stop & Bearings

604713

8

200V Left Steering Pivot with Stop & Bearings

604714

9

Sleeve Bearing with Flange

422556

10

Sleeve Bearing

422557

11

Hex Bolt .312-18 x .75

243197

12

Washer

257063

13

Nylon Insert Nut

253470

14

Compression Spring

283324

15

Flat Washer

257019

16

Thumb Screw

252858
