1

Pump Plate - 325 / 400

644633

2

Hydro Pump - left

391452

3

Hydro Pump - right

391453

4

Steering Linkage Rod - 300S

604527

5

Ball Joint

265615

6

Nut

254441

7

Ball Joint - Lefthand Thread

265616

8

Nut

254444

9

Rectangle Key

281562

10

Control Arm

725338

11

Ball Stud

265680

12

Whiz Nut

253035

13

Idler Spring Bracket - M1

732520

14

Eccentric Roller Assembly

603726

15

External Star Washer

257410

16

Nut

254450

17

Hex Whiz Bolt

253182

18

Whiz Nut

253025

19

Neutral Return Mount - right

729225

20

Neutral Return Mount - left

729229

21

Neutral Return Front Arm - right

729136

22

Neutral Return Front Arm - left

729137

23

Neutral Return Arm - right

729138

24

Neutral Return Arm - left

729139

25

Extension Spring

283823

26

Neutral Return Pivot Bearing

822304

27

Washer

257040

28

Hex Bolt

243335

29

Lock Nut

253890

30

300S Anti Rotation Bracket

755057

31

Clutch Bracket Cover

422088

32

Sheave

415901

33

Sheave

415898

34

Idler Arm

824484

-

Oilite Bearing

121756

35

Pedestal Bearing

121650

36

Hex Bolt

243360

37

Lock Washer

257412

38

Idler Pulley

393195

39

Washer

257062

40

Hex Bolt

243601

41

Lock Washer

257432

42

Nut

254470

43

Nylon Bearing

422558

44

Lock Nut

253930

45

Hex Bolt

243580

46

Nut - Flanged with Counter Bore

830351

47

Extension Spring with Swivel

283820

48

Flange Whiz Bolt

253203

49

Belt

382035

50

Electric Clutch

388740

51

Hex Flange Whiz Bolt

253192

52

right Pump Plate Shield

723242

53

left Pump Plate Shield

723243

54

Square Key (Round End)

281670

55

Damper

285031

56

Rear Belt Shield Isolator

422090

57

Rear Belt Shield Isolator

422090

58

Rear Shield Assembly - M1 321D / 325

604754

59

Rubber Latch Draw

281301

60

Whiz Nut

253038

61

Spring Assembly

604776

62

Idler Adjustment J Bolt

730391

63

Hex Bolt

243340

64

Lock Washer

257422

65

Hex Bolt

243349

66

Mule Drive Idler Arm

824486

67

Washer

257030

68

Whiz Nut

253043

69

Idler

393376

70

Hex Bolt

243355

71

Hex Bolt

243570

72

Hex Bolt

243035

73

Idler Pulley

393390

74

Hex Bolt

243585

75

Retainer Washer

883804

76

Belt (for 52" and 61" decks)

382095

-

Belt (for 72" deck)

382098

77

10A Fan Mount Hub

885123

78

7" Nylon Fan

320857

79

Washer

774020

80

Nut

254452
