Item # |
Description |
Part Number |
1 |
Frame - |
645210 |
2 |
Upper Frame Notched |
645205 |
3 |
Step Bushing |
257037 |
4 |
Washer |
774020 |
5 |
Hex Bolt |
243215 |
6 |
Nylon Insert Nut |
253450 |
7 |
335 Console Panel |
721265 |
8 |
Muffler Shield Bracket |
766160 |
9 |
Tank Rail - right |
754051 |
10 |
Tank Rail - left |
754052 |
11 |
Hex Flange Whiz Bolt |
253192 |
12 |
Whiz Nut |
253035 |
13 |
Gas Tank Anchor |
722194 |
14 |
Whiz Nut |
253025 |
15 |
Truss Whiz Bolt |
253176 |
16 |
Compression Spring |
283516 |
17 |
Whiz Flange Bolt |
253203 |
18 |
Whiz Nut .375-16 |
253043 |
19 |
Seat Spring Cap |
422127 |
20 |
Battery Box with Strap |
644108 |
21 |
Battery Tray Pad |
427275 |
22 |
Battery Hold-down Strap |
604785 |
23 |
M1 Gas Tank Assembly |
604800 |
24 |
Fuel Cap |
100210 |
25 |
Fuel Tube |
363921 |
26 |
8.5 gal. In-Tank Fuel Gauge |
141140 |
- |
Grommet - Fuel Gauge Mount |
424275 |
27 |
Fuel Tube Bushing (Grommet) |
101875 |
28 |
Speed Nut |
254431 |
29 |
Hex Bolt |
243225 |
30 |
M1 Tank Shield |
722495 |
31 |
329B/335 Fender RT |
644428 |
32 |
329B/335 Fender LT |
644429 |
33 |
Trim |
822632 |
34 |
Hex Whiz Bolt |
253173 |
35 |
Work Lamp Hole Plug |
422079 |
36 |
Cup Holder |
150225 |
37 |
Cap Screw |
259030 |
38 |
Nut |
254436 |
39 |
Lug Bolt |
248565 |
40 |
Wheel & Tire 24 x 12 x 12 |
483965 |
- |
Turf Tire 23 x 10.5 x 12 |
482485 |
- |
Turf Tire 24 x 12 x 12 |
482486 |
- |
Bar Tread Tire Only 24 x 12 x 12 |
482487 |
- |
Wheel Only 12 x 8.5 x 4.25 (for 61" & 72" Decks) |
483440 |
- |
Wheel Only 12 x 8.5 x 5.750 (for 52" Decks) |
483445 |
- |
Wheel & Tire 23 x 10.5 x 12 |
483960 |
- |
12" Wheel & Bar Tread Tire (right) |
483968 |
- |
12" Wheel & Bar Tread Tire (left) |
483969 |
41 |
Belt Guard Strap |
783277 |
42 |
M1 On Frame Footrest |
644256 |
43 |
Foot Rest Tread |
420902 |
44 |
Seat Isolator |
424095 |
45 |
Seat Hinge Pin |
644618 |
46 |
Throttle Assembly |
604831 |
- |
Throttle Control Cable |
323650 |
- |
Throttle Lever Stop |
722009 |
47 |
Handle Grip |
422150 |
48 |
Fuel Hose |
821738 |
49 |
Spring Hose Clamp |
280260 |
50 |
Mechanical Choke |
142214 |
51 |
300 right Hydro Debris Shield |
723050 |
52 |
300 left Hydro Debris Shield |
723051 |
53 |
29 HP b & S AC M1 Engine |
100191 |
54 |
Air Cleaner |
100209 |
- |
Air Hood |
100203 |
- |
Air Filter Outer HD |
100936 |
- |
Air Filter Inner HD |
100937 |
55 |
Muffler |
101255 |
56 |
Oil Filter - Briggs |
100803 |
57 |
In-Line Fuel Filter Briggs |
366560 |
58 |
Hex Bolt |
243445 |
59 |
90 Degree Adapter |
887124 |
60 |
Jam Nut |
254716 |
61 |
Aluminum Washer |
773010 |
62 |
Oil Drain Valve |
143610 |
63 |
Nylon Fitting |
363854 |
64 |
Oil Drain Tube |
821752 |
65 |
Muffler Shield |
722837 |
66 |
Muffler Shield - Outer |
722841 |
67 |
Washer |
257051 |
68 |
Lock Washer |
257422 |
69 |
Exhause Extension |
733682 |
- |
Muffler Clamp |
101370 |
70 |
Step Bushing |
257038 |
71 |
329B Decal Set |
605347 |
